Typical Applications
• Automotive dealerships
• Fast lube centers
• Lube trucks
• Lubricant transfer
• Service shops
Sound Pressure Level, calculated at a distance of 1 meter from measurements taken per ISO 9614–2 @ 100 psi air pressure (6.89 bar, 0.68 MPa) and 20 cycles per minutes. Muffler 112933 can be ordered separately for reduced sound levels.
Sound Power Level, measured per ISO 9614–2 at 100 psi air pressure (6.89 bar, 0.68 MPa) and 20 cycles per minute. Muffler 112933 can be ordered separately for reduced sound levels.
| Maximum Fluid Working Pressure | 51.7 bar, 5.17 MPa |
|---|---|
| Fluid Pressure Ratio | 3:1 or 5:1 |
| Suction Lift (feet of oil) | 10 |
| Air Operation Range | 1.37 to 10.3 bar, 0.137 to 1.03 MPa |
| Recommended Air Pressure for Optimum Pump Life |
8.6 bar, 0.86 MPa |
| Air Consumption (at 100 psi) | See Performance Curves in instruction manual 3A1334 |
| Cycles per gallon (liter) | 3:1 – 7 cycles/l, 5:1 – 10 cycles/l |
| Maximum Recommended Pump Speed | 3:1 – 120 cycles/min, 5:1 – 180 cycles/min |
| Recommended Speed for Optimum Pump Life |
75 cycles/min and lower, 3:1 – 9.8 l/min, 5:1– 7.6 l/min |
| Wetted parts | zinc plated carbon, steel, aluminum, nitrile, polyurethane, nickel plated aluminum |
| Performance Curve | See Chart in instruction manual 3A1334 |
| Approximate Weight | 35 lb drum – 5.1 kg, 120 lb drum – 6.8 kg, 400 lb drum – 7.7 kg |
