72.9 dB(a) Sound Pressure Level, calculated at a distance of 1 meter from measurements taken per ISO 9614–2 @ 100 psi air pressure (6.89 bar, 0.68 MPa) and 20 cycles per minutes. Muffler 112933 can be ordered separately for reduced sound levels.
82.0 dB(a) Sound Power Level, measured per ISO 9614–2 at 100 psi air pressure (6.89 bar, 0.68 MPa) and 20 cycles per minute. Muffler 112933 can be ordered separately for reduced sound levels.
| Maximum Fluid Working Pressure | 517 bar, 51.7 MPa |
|---|---|
| Fluid Pressure Ratio | 50:1 |
| Air Operation Range | 1.37 to 10.3 bar, 0.137 to 1.03 MPa |
| Air Consumption (at 100 psi) | See performance curve in instruction manual 3A1334 |
| Pump Cycles per pound (cycles per kg) | 103 cycle/kg |
| Maximum Recommended Pump Speed | 120 cycles/min |
| Recommended Speed for Optimum Pump Life | 60 cycles/min or lower flow rate, 0.6 kg/min |
| Wetted parts | steel, brass, nitrile rubber, polyurethane, UHMWPE, acetal |
| Performance Curve |
See Chart in instruction manual 3A1334 |
| Approximate Weight | 35 lb drum – 5.1 kg, 120 lb drum – 6.8 kg, 400 lb drum – 7.7 kg |
