| Maximum Fluid Working Pressure | 7 bar, 0.7 MPa |
|---|---|
| Air Pressure Operating Range | 2.1 to 7 bar, 0.2 to 0.7 MPa |
| Maximum air consumption | 0.672 m³/minute |
| Maximum free-flow delivery | 61 lpm |
| Maximum pump speed | 400 cpm |
| Gallons (Liters) per cycle | 0.15 |
| Maximum suction lift (water with buna balls) | 4.5 m dry, 7.6 m wet |
| Maximum size pumpable solids | 2.5 mm |
| Operating Temperature Range | Minimum, all pumps 4°C |
| Operating Temperature Range | Maximum, acetal pumps 82°C |
| Operating Temperature Range | Maximum, polypropylene pumps 66°C |
| Operating Temperature Range | Maximum, aluminum, stainless steel, PVDF pumps 107°C |
