| Maximum fluid working pressure | 8 bar, 0.8 MPa |
|---|---|
| Air pressure operating range | 1.4-8 bar, 0.14-0.8 MPa |
| Maximum air consumption | 175 scfm |
| Air consumption at 70 psi (0.48 MPa, 4.8 bar)/60 gpm | 60 scfm |
| Maximum free-flow delivery | 568 lpm |
| Maximum pump speed | 145 cpm |
| Gallons (liters) per cycle | 3.90 l |
| Maximum suction lift | 5.48 m wet or dry |
| Maximum size pumpable solids | 6.3 mm |
| Maximum noise level* at 100 psi (7.0 bar, 0.7 MPa) and 50 cpm | 90 dBa |
| Sound power level, sound power measured per ISO Standard 9216 | 103 dBa |
| Noise level at 70 psi (4.8 bar, 0.48 MPa) and 50 cpm | 85 dBa |
| Maximum Operating Temperature Models with PTFE diaphragms | 93.3°C |
| Maximum Operating Temperature Models with other diaphragms | 65.5°C |
| Air inlet size | 1/2 npt(f) |
| Fluid inlet size | 2 in npt(f) |
| Fluid outlet size | 2 in npt(f) |
| Non-wetted external parts | Aluminum, 302 and 316 stainless steel, polyester (labels) |
| Weight Aluminum pumps | 26.3 kg |
| Weight Stainless steel pumps with aluminum center section | 50.3 kg |
| Weight Ductile iron pumps with stainless steel center section | 59.0 kg |
| Weight Stainless steel pumps with stainless steel center section | 61.0 kg |
