| Maximum Fluid Working Pressure | 58 MPa/580 bar |
|---|---|
| Maximum Air Inlet Pressure | 1.0 MPa/10 bar |
| Ratio | 50:1 |
| Pump Cycles | 130/.45 kg |
| Maximum recommended pump speed | 100 cycles/min |
| Recommended pump speed for continuous operation | 60 cycles/min |
| Maximum Delivery | .25 kg/min at 60 cycles/min |
| Stroke Length | 50.8 mm |
| Maximum Pump Operating Temperature | 54 °C |
| Air Inlet Size | 3/8 npt (f) |
| Fluid Outlet Size | 1/4 npt (f) |
| Wetted Parts | Carbon steel; zinc plating; brass; polyurethane; ultra-high molecular weight polyethylene; Buna-N |
| Sound Pressure Level (measured 1 meter from unit) | 77.8 db(A) @ 140 psi, 100 cpm |
| Sound Power Level (tested in accordance with ISO 9614–2) | 85.6 dB(A) @ 140 psi, 100 cpm |
| Approximate Weight | 6.8 kg |
