| Fluid pressure ratio | 75:1 |
|---|---|
| Air pressure operating range | 40 to 100 psi or 0.3 to 0.7 MPa, 3 to 7 bar |
| Maximum working pressure | 7500 psi or 51.7 MPa, 517 bar |
| Maximum delivery | 0.33 gpm or 1.3 lpm |
| Cycles per gallon (liter) | 42 |
| Maximum recommended pump speed | 60 cycles/minute |
| Air motor effective diameter | 108 mm |
| Stroke | 102 mm |
| Air consumption | approximately 26 cfm at 1 gpm, at 70 psi or approximately 0.72 m3/min at 1 gpm, at 0.5 MPa, 5 bar |
| Wetted Parts | steel, brass, aluminum, leather |
| Weight Model 239729 | 15 kg |
| Weight Model 239730 | 17 kg |
| Weight Model 239731 | 14 kg |
