| Maximum working pressure | 76 bar, 7.6 MPa |
|---|---|
| Fluid pressure ratio | 6:1 |
| Air operating range | 3 to 12 bar, 0.3 to 1.2 MPa |
| Air consumption | 7 ft³/min per gallon pumped (0.051 m³/min per liter pumped) at 100 psi (7 bar, 0.7 MPa) |
| Pump cycles per gallon (liter) | 3.8 Liters |
| Maximum recommended pump speed | 23 liter/min |
| Recommended speed for optimum pump life | 15 to 25 cycles per min |
| Piston seals | polyurethane with nitrile spreader |
| Rod seals | polyurethane with nitrile spreader |
| Wetted parts | aluminum, steel, polyurethane, nitrile |
| Approximate weight | 21 kg |
| Sound pressure level | 79.5 dB(A) |
