| Maximum fluid working pressure | 7500 psi or 51.7 MPa, 517 bar |
|---|---|
| Air pressure operating range | 40 to 150 psi or 0.3 to 1 MPa, 3 to 10 bar |
| Fluid pressure ratio | 50:1 |
| Maximum delivery | 0.5 gpm or 1.9 lpm |
| Cycles per gallon (per liter) | 110 |
| Maximum recommended pump speed | 60 cycles per minute |
| Air motor effective diameter | 108 mm |
| Stroke | 102 mm |
| Air consumption | approximately 19 cfm at 1 gpm at 70 psi or approximately 0.53 m3/min at 3.8 lpm at 0.48 MPa, 4.8 bar |
| Wetted parts | Steel, brass, aluminum, leather |
| Weight Model 205394 | 15 kg |
| Weight Model 205395 | 17 kg |
