| Maximum working pressure | 3.7 MPa, 37 bar |
|---|---|
| Fluid pressure ratio | 3:1 |
| Air operating range | 0.28 to 1.2 MPa, 2.8 to 12 bar |
| Air consumption | 3 ft³/min per gallon pumped, (0.022 m3/min per liter pumped) up to 8 ft³/min (0.058 m³/min) with pump operating within recommended range Pump cycles per gallon (liter) 1.6 Liters |
| Maximum recommended pump speed | 66 cycles/min; 45 lpm |
| Recommended speed for optimum pump life | 15 to 25 cycles per min |
| Piston seals | Polyurethane |
| Rod seals | Nitrile |
| Wetted parts | aluminum, steel, nitrile |
| Approximate weight | 21 kg |
| Sound pressure | 82 dB(A) |
