| Fluid pressure ratio | 10:1 |
|---|---|
| Air pressure operating range | 3–12.4 bar, 0.3–1.2 MPa |
| Maximum working pressure | 124 bar, 12.4 MPa |
| Maximum delivery | 19.7 lpm |
| Cycles | 6 per 1 |
| Max. recommended pump speed | 60 cycles per minute |
| Air motor effective diameter | 108 mm |
| Stroke | 102 mm |
| Air consumption | approx. 6 m/hr³/l 0.7 MPa, 7 bar |
| Wetted parts | steel, brass, aluminum, leather, Buna–N |
| Weight | 17 kg |
| Sound Pressure Level (Input Air Pressures at 15 cycles per minute) | (Measured at 1 m from unit) 0.28 MPa, 2.8 bar; 73.6 dB(A): 0.48 MPa, 4.8 bar; 78.34 dB(A): 0.7 MPa, 7 bar; 80.85 dB(A) |
| Sound Power Level (Input Air Pressures at 15 cycles per minute) | (Tested in accordance with ISO 9614–2) 0.28 MPa, 2.8 bar; 87.4 dB(A): 0.48 MPa, 4.8 bar; 92.09 dB(A): 0.7 MPa, 7 bar; 94.62 dB(A) |
