| Maximum fluid working pressure | 8400 psi or 58 MPa, 580 bar |
|---|---|
| Air pressure operating range | 30 to 140 psi or 0.3 to 0.97 MPa,3 to 9.7 bar |
| Maximum air consumption | 22.8 scfm at 0.25 gpm at 100 psi or 0.638 m3/minute at 0.95 liter/min at 0.7 MPa, 7 bar |
| Maximum recommended pump speed | 76 cycles/min at 0.22 gpm |
| Cycles per gallon (liter) | 345 |
| Sound pressure level (measured at 1 meter from unit) | 77.8 dB(A) |
| Sound power level (tested in accordance with ISO 9614-2) | 85.6 dB(A) |
| Wetted Parts | Steel, brass, aluminum, acetal, nitrile rubber, polyurethane |
| Approximate weight | 10 kg |
