| Maximum working pressure | 186 bar |
|---|---|
| Fluid pressure ratio | 15:1 |
| Air operating range | 3 to 12 bar |
| Air motor effective diameter | 76 mm |
| Stroke | 76 mm |
| Air consumption | 0.476 sq m/l at 7 bar. Up to 0.84 sq m/min with pump operated at 12 bar and 66 cycles/min |
| Pump cycles | 24 cycles/l |
| Delivery | 3 l/min |
| Maximum recommended continuous pump speed | 66 cycles/min, 32 l/min |
| Recommended speed for optimum pump life | 15 to 25 cycles/min |
| Wetted parts | Carbon Steel, Brass, Copper, Aluminum, PTFE, Nitrile Rubber, Leather |
| Approximate | 10 kg |
